Complete Door and Door Accessories Provider for Commercial/Residential/Industrial garage usage
7 Years
| Ask Lasest Price | |
| Brand Name : | FAMOUS |
| Model Number : | None |
| Certification : | CE/ ISO 9001 |
| Price : | USD80-200 per Square meter |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 1000 sets per month |
| Delivery Time : | 15 days |
Description:
High Speed PVC Door is widely used in modern factories and
warehouses. It can run in very high speed (up to 2.5m/s)and
frequency (up to 2000 times/day), very fit for areas with heavy
traffic. Air flow through the door is reduced obviously, to protect
indoor environment. Automatic running is realized with programmed
control system and sensors. Automatic and high performance speed
door is also the solution to the environment which needs prevent
dust and clean easily in the busy passageway area with high
clearness demands,strong wind- pressure,especially in the
food,pharmacy, and fine machining industry.
Specifications:
| PVC High Speed Rolling Door | |
| Size | 6000mm( W)*8000( H),actual size: cutomized as order; |
| Speed (frequency control system) | opening 1.5m/s (adjustable); closing 1.2m/s (adjustable) |
| Material | 1. 1.5mm coating galvanized steel; 2.0mm aluminum alloy; 2.0mm 304
stainless steel, food grade , chemical proof ; 2. 0.8mm/1.2mm/1.5mm PVC plastic fabric; |
| Color | Blue,Yellow,Red,Grey,White,Full-clear,etc |
| Safety Device | photoelectricity / airbag / bollards |
| Opening Device | Button / radar / remote control / rocker / geomagnetism / pull switch / swipe fingerprint machine, etc. |
| Control Systerm | Domestic or Foreign motor brands ( PLC, transducer, switching power supply, breaker, etc.) |
| Motor(power supply) | 380V (3phase)or 220V(1phase )/50HZ 0.75KW/ 1.1KW/1.5KW |
| Main Features | 1. Box cover and track are made of high strength aluminum alloy
that is treated by oxidation, both beautiful and durable; 2. New and beautiful aluminum alloy intergral bottom beam, whose bottom can be installed with safety rubber protection device; 3. Removeable windproof aluminum alloy rib makes the curtain replacement more convenient; 4. The system will automatically turn off the power when the door hasn't run for 30 minutes, the system will restart within 10 milliseconds once there is a new signal. It can save 30%electricity compared to the traditional system; 5. With most advanced control system which has many advantages, such as high speed, high stability, high precision, and intellignent . |
Production processes:
Features:
1. High intensity fire insulation, sound insulation, spray the
surface corrosion.
2. Install tamper device, effectively protect your property.
3. Bearing pulleys easy adjustment to ensure smooth lifting process
without noise
4. Double security guards, fall protection + anti-fracture "
5. Using frequency: 2000 times a day
6. Convenient to operate
7. Visible window available
PVC rapid action rolling door / roll up door
1. For door decorating, Accessories according to the European
standard
2. Manual or remote operation available
3. Middle, exterior and interior installation
Advantages:
Safe: This kind of door use infrared sensor and airbag which can
ensure huaman's safety. The door will stop closing quickly when
someone go across.
Long lifetime: The cover box use 2.0mm high quality galvanized
steel which can protect door from bad environment so that the can
work long time.
Faster: This kind of door use imported SEW motor so that the open
speed can reach 2.5/s max and close speed can reach 1.2m/s.
Easy to clean: The curtain use imported PVC fabric which can clean
easily.
Save energy: The system will turn off the power automatically when
the door hasn't work for 30 minutes, and the system will restart
within 10 milliseconds once there is a new signal.
